The defining technological asset of the 3M GT7100 High Performance family is its exceptional stress-relaxation behavior and multi-substrate adhesion. Automotive exterior parts (such as weatherstrips, body side moldings, and radar brackets) are exposed to extreme aerodynamic drag, continuous highway vibrations, and severe expansions between different materials (CTE). The viscoelastic core of GT7104, GT7106, and GT7112 flows dynamically to distribute stress uniformly along the entire bond line, while providing an unyielding, weather-tight chemical seal that prevents water ingress, stone-chip delamination, and corrosion.
Key Features & B2B Benefits
For automotive trim factory directors, Tier-1 exterior module suppliers, and precision automotive die-cutters, the 3M GT7100 High Performance Series delivers a flawless assembly solution:
3M GT7100 High Performance Pedigree: Fully validated under global automotive OEM specifications, ensuring reliable adhesive performance on traditional clear coats, advanced low surface energy (LSE) paints, and chrome-plated plastics.
Calibrated Thickness Gradient (0.4mm to 1.2mm):
GT7104 (0.4mm): Optimized for ultra-flush, low-profile lettering, sharp emblems, and narrow garnish lines where clearance space is tight.
GT7106 (0.6mm): The versatile benchmark gauge for medium-profile emblems, sensors, and sleek interior/exterior trim bezels.
GT7112 (1.2mm): Engineered with maximum gap-filling and high strain-cushioning for heavy body side moldings, spoilers, and curved weatherstrips.
Viscoelastic Shear Strength: Absorbs severe dynamic shocks and high peel stresses, ensuring heavy exterior components remain pinned down at autobahn speeds.
All-Weather Automotive Resistance: Impervious to continuous UV radiation, automatic car wash detergents, gasoline/diesel splashes, and intense thermal cycles (from sub-zero winter temperatures to blistering hot hoods).
TDS
|
Material & Performance Property |
3M GT7104 |
3M GT7106 |
3M GT7112 |
Testing Standard / Method |
|
Series Classification |
GT7100 High Performance |
GT7100 High Performance |
GT7100 High Performance |
Automotive OEM Approved Matrix |
|
Foam Core Chemistry |
Viscoelastic Acrylic |
Viscoelastic Acrylic |
Viscoelastic Acrylic |
Medium-Density Closed-Cell Core |
|
Total Tape Thickness |
0.40 mm / 16 mil |
0.60 mm / 24 mil |
1.20 mm / 47 mil |
ASTM D-3652 Precision Sensor |
|
Visual Tape Color |
Gray |
Gray |
Gray |
Blends Safely with Car Body Lines |
|
Release Liner Type |
Orange Polyethylene (PE) |
Orange Polyethylene (PE) |
Orange Polyethylene (PE) |
Formulated for Robotic Application |
|
Adhesion to Steel |
20 N/cm |
22 N/cm |
24 N/cm |
ASTM D-3330 180° Peel (Aged) |
|
Static Shear Resistance |
High-Cohesion Holding |
High-Cohesion Holding |
High-Cohesion Holding |
Resists Continuous Dead Load Stress |
|
Short-Term Thermal Limit |
+120°C / +248°F | +120°C / +248°F | +120°C / +248°F |
Paint Baking / SMT Pass Window |
Detailed Thickness Breakdown & Specific Application Fields
The primary differentiator across these three models is their thickness gradient (0.4mm → 0.6mm → 1.2mm), which dictates their dynamic gap-filling capacities and strain-cushioning limits in assembly lines.

3M GT7104 (Thickness: 0.40 mm / 16 mil)
Design Intent: Ultra-thin, high-precision, flush invisible bonding.
Application Advantage: Engineered for applications with microscopic gap tolerances and perfectly planar mating surfaces. It keeps components flush with the car body, maintaining clean, uncompromised aerodynamic lines.
Primary Fields:
High-precision 3D model scripts, car rear individual letters (lettering), and sharp brand badges.
Sleek interior and exterior gloss-black or chrome accent trims on side mirrors.
Sealing and mounting compact electronic sub-components, such as rearview camera housings and dashcam assemblies.

3M GT7106 (Thickness: 0.60 mm / 24 mil)
Design Intent: Universal benchmark for mid-profile exterior attachments.
Application Advantage: The industry-standard gauge balancing high initial peel strength with micro-level tolerance compensation. It absorbs surface irregularities while resisting substantial lateral shear.
Primary Fields:
Mid-sized car emblems, automotive corporate logos, and high-gloss plastic B-pillar garnishes.
Internal Advanced Driver Assistance Systems (ADAS) sensor brackets and ultrasonic parking sensor housings mounted behind bumpers.
Waterproof mounting of roof-top shark-fin antennas and auxiliary LED third brake lights.

3M GT7112 (Thickness: 1.20 mm / 47 mil)
Design Intent: Heavy-duty, large-gap filling and maximum vibration dampening.
Application Advantage: The most resilient and shock-absorbent model in the trio. If a part has a curved profile or encounters severe structural warpage during thermal cycling, the 1.2mm deep foam acts as a dynamic cushion, filling microscopic gaps on rough or textured surfaces.
Primary Fields:
Heavy-duty automotive body side moldings, door claddings, wheel arch extensions, and anti-rub strips.
Rigid resin window rain guards (weatherstrips), roof ditch moldings, and aerodynamic trunk spoilers.
Exterior plastic protective undertrays, EV battery pack outer covers, and charging port door modules on New Energy Vehicles (NEVs).
Processing automotive-grade acrylic foam tapes requires high-tonnage precision converting to avoid edge-welding and core distortion. STK directly optimizes your automotive assembly line:
Burr-Free Clean-Edge Die-Cutting: Automotive automated assembly lines cannot tolerate edge-oozing or lint contamination. STK processes 3M™ GT7104, GT7106, and GT7112 via computerized rotary and flatbed die-cutting presses, delivering precision gaskets directly on easy-to-peel continuous liners.
Custom Extended Tabs & Pull-Handles: To drastically cut down cycle times on manual assembly lines, STK customizes die-cut parts with extended non-adhesive PET pull-tabs, allowing operators to strip release liners cleanly in seconds without affecting the glue face.
Precision Custom Slitting Rolls: Need precise ribbon widths for automatic tape-application robots? STK slits the GT7100 family down to narrow widths (e.g., 4mm, 6mm, 9mm, 12mm) with laser-straight roll faces, preventing unwind drag.

Global Lead Times
Industrial Packaging
Packaged in vacuum-sealed moisture-barrier cartons, securely stacked onto heavy-duty pallets to protect delicate pure adhesive edges from pressure deformation or humidity during overseas transit.
Standard Dispatches
Warehouse stock configurations are checked, packed, and loaded for shipping within 3–5 working days with complete GHS MSDS data sheets.
Custom OEM Slitting Orders
Custom roll widths or specific long-length spools are slit, quality-audited via digital calipers, and dispatched within 5-9 working days post blueprint lock.
